1. This machine is multi-fuctional. Various bricks such as road verge bricks,river channel bricks,slope-protecting bricks,plaza pavement bricks,dock bricks,grass-planting bricks etc. can be produced only by exchanging its mould.
2.By low frequency material feeding,high frequency vibrating and pressing and vibrating both by table and mould, the concrete can be completely liquidized and air discharged within 2 or 3 seconds, in order to obtain high density and high strength.
3.As the advanced hydraulic ratio control technology is adopted so that the oil pressure of each branch of the circuit can be controlled at will and various bricks with the same high quality can be produced using different raw materials.
4.PLC intelligent control system which equipped with data input and output device,advanced safety logic and fault self-diagnosis system is adopted in full of the production procedure.

host machine size	2700*1600*2500mm	host machine weight	4.5t
block making period	15-20s	pallet size	880*580*22
vibrating force	30-50kn	Voltage	Adopt to local voltage
host machine power	24kw	work shop area	250-300m2

Name	block size	block making period	blocks per mold	Production capacity
Hollow block	400x200x200	15-20s	4	720-960pcs/hour
Multi-hole brick	240x115x90	15-20s	12	2160-2280pcs/hour
Solid brick	240x115x53	15-20s	26	4680-6240pcs/hour
paver	200x100x60	20s	16	2880pcs/hour
Ishape paver	200x163x60	20s	12	2160pcs/hour

Finished blocks
